Backseat Entertainment & Climate Control Screen V1 For Tesla Model 3/Y 2017-2023
DISCONTINUED
The rear entertainment screen you have been waiting for! Works with Tesla Model 3 and Y
Due to immense demand, Pimp My EV is pleased to introduce a brand new rear entertainment screen for Tesla Model 3 2017-2023 and Tesla Model Y 2020-2023.
Inspired by the Tesla Model S and X 2022 refresh, your Model 3 and Model Y now can also have a rear display!
This screen runs on the Android 11 OS and comes fully featured with the Play Store. The screen talks to your Tesla to control essential functions for rear passengers that have not been available before!
⇨ Non destructive installation : Fits right on top of the rear AC vent cover with the supplied fitting, wires and tools to get the job done! There is no need to drill, and the interior of your Tesla Model 3 or Model Y will not be damaged during the installation process.
⇨ Google Play Store: Android OS 11 with google play store to download and use the apps you love!
⇨ Control Climate: Rear passengers are now able to control the climate controls with ease without bothering the driver.
⇨ Control Volume: Volume can be controlled right from the display for the whole car for immersive theater like entertainment or individual control for Bluetooth headsets.
⇨ Bluetooth and WiFi: Built in Bluetooth to ensure seamless connectivity to your wireless headphones for isolated rear passenger entertainment. WiFi function to run off your Mobile WiFi sharing access point.
FEATURES & DATA:
- 8.8 inch display 1280x720 pixels high definition LCD panel.
- Control the main display for volume (up/down) and play / pause.
- Heated seat controls for each individual seat
- Temperature and fan controls
- Built in Bluetooth 5.0 chip (connect multiple head sets for simultaneous listening)
- WiFi Internet Access, Online Music, Games and Internet TV
- Support for wireless Apple Car Play & Android Auto.
- Sound controls to work for headphones or through car speakers for a theater like experience
- Built in speakers for a 3rd option for sound.
- Comes with USB-C and USB-A plates for the rear AC vent.
COMPATIBILITY:
Tesla Model 3 2017-2022 Intel Versions
Tesla Model 3 2021-2024 AMD Versions
Tesla Model Y 2020-2021 Intel Versions
Tesla Model Y 2021-2024 AMD Versions
Please select the appropriate car from the selection drop down shown above.
FEATURES AND COMPARISON
| Feature | Rear Entertainment Screen V1 | Rear Entertainment Screen V2 | Climate Control Screen |
| Screen Size | 8.8 inches | 7 Inches | 4.6 inches |
| Resolution | 1280x720 | 1024x600 | 960x320 |
| Media controls | Yes | Yes | Yes |
| Climate Control | Yes | Yes | Yes |
| Media playback | Yes | Yes | No |
| Google store | Yes | Yes | No |
| Wifi | Yes | Yes | No |
| 4G | Partial GSM |
No | No |
| Apple Car Play | Yes | Yes | No |
| Android Auto | Yes | Yes | No |
| Bluetooth For Headphones | Yes | No |
No |
| USB A & USB C Front Plates | Yes | Universal plate | Yes |
| Built In Speaker | Yes | No | No |
| AMD & Intel Compatibility | Yes | Yes | Yes |
| Model 3 Compatible | Yes | Yes | Yes |
| Model Y Compatible | Yes | Yes | Yes |
| Model X Compatible | No | No | No |
| Model S Compatible | No | No | No |
| Works when the car is in Drive | Yes | Yes | Yes |
FAQS:
Will the multimedia work when the car is in drive?
Yes, it will work when the car is in drive mode as the screen has its own isolated operating system which is only accessible by rear passengers.
How do I check if I have a Intel or AMD processor?
You can follow this video on how to check which processor you have
How is it mounted?
The screen is mounted on a replacement AC vent cover. The original AC vent cover needs to be removed and replaced with the one that comes with this screen.
Does it support English Language?
Yes, the screen / tablet supports the US, UK and International English language.
Does the screen share the car's internet connection or does it need its own?
The car does not share its internet connection with anything apart from its own computer. The rear screen will need its own internet connection with a mobile WiFi hotspot. The climate control and multimedia controls from the screen will not need an internet connection as that is plugged directly into the ODB2 port.
Can I connect headphones to it?
Yes, you can connect wireless bluetooth headphones to the screen.
Can I connect this alongside a front screen?
Yes, you can connect the wires supplied with this product in a sequence with other wires that go into the main computer. This is also called daisy chain. Connecting 2 wires in sequence works fully and does not impact the operation of this device.
REVIEW BY SHIVA SAPKOTA:
REVIEW BY NICOLAS TESLA (FRENCH):
REVIEW BY THE MEGAWATTS
INSTALLATION:
The installation of this mod is an involved process, but it is definitely worth the reward. Installation difficulty is 5 out of 10. Installation takes 1 to 2 hours with testing.
A step by step installation guide in the form of a video is available above to view. We have 3 of those, one in french.
WIRING INSTRUCTIONS AMD AND INTEL:
For ultimate quality and an overall superior aesthetic, the Rear Entertainment & Climate Control Screen For Tesla Model 3/Y 2017-2023 is your ultimate choice. SECURE YOURS NOW!
SHIPPING:
This item is shipped directly from our warehouse overseas.
All efforts are made to ensure your item gets to you in perfect condition and ready for installation.
No quibble 30-day refund or replacement from the day of delivery if the item is damaged or not fit for purpose.
Placement on Vehicle: Rear Air Flow Vent Cover
Item Type: Rear Entertainment Tablet
Fit: Tesla Model 3 & Y
